While LLMs are powerful, their actions are limited to content generation. To enable them to interact with the world, perform tasks, and access real-time information, whether it’s reading a file, querying a database, or making an API call, we can use MCP (Model Context Protocol) which is a standardized way for LLMs to interact with external systems.
The MCP protocol was designed by anthropic as a standard way for AI applications and agents to connect to and work with your data sources (e.g. local files, databases, or content repositories) and tools (e.g. GitHub, Google Maps, or Puppeteer).
At a very high level, MCP has three participants:
Install the Google GenAI SDK from npm.
$ npm install @google/genaiYou can create your API key using Google AI Studio with a single click.
Remember to treat your API key like a password. Don’t accidentally save it in a notebook or source file you later commit to GitHub. In this notebook we will be storing the API key in a .env file. You can also set it as an environment variable or use a secret manager.
Here’s how to set it up in a .env file:
$ touch .env
$ echo "GEMINI_API_KEY=<YOUR_API_KEY>" >> .envAnother option is to set the API key as an environment variable. You can do this in your terminal with the following command:
$ export GEMINI_API_KEY="<YOUR_API_KEY>"To load the API key from the .env file, we will use the dotenv package. This package loads environment variables from a .env file into process.env.
$ npm install dotenvThen, we can load the API key in our code:
const dotenv = require("dotenv") as typeof import("dotenv");
dotenv.config({
path: "../../.env",
});
const GEMINI_API_KEY = process.env.GEMINI_API_KEY ?? "";
if (!GEMINI_API_KEY) {
throw new Error("GEMINI_API_KEY is not set in the environment variables");
}
console.log("GEMINI_API_KEY is set in the environment variables");GEMINI_API_KEY is set in the environment variablesIn our particular case the .env is is two directories up from the notebook, hence we need to use ../../ to go up two directories. If the .env file is in the same directory as the notebook, you can omit it altogether.
│
├── .env
└── examples
└── mcp
└── Building_a_MCP_server.ipynbNow select the model you want to use in this guide, either by selecting one in the list or writing it down. Keep in mind that some models, like the 2.5 ones are thinking models and thus take slightly more time to respond (cf. thinking notebook for more details and in particular learn how to switch the thiking off).
const tslab = require("tslab") as typeof import("tslab");
const MODEL_ID = "gemini-2.5-flash";With the new SDK, now you only need to initialize a client with you API key (or OAuth if using Vertex AI). The model is now set in each call.
const google = require("@google/genai") as typeof import("@google/genai");
const ai = new google.GoogleGenAI({ apiKey: GEMINI_API_KEY });In this example, you will create a simple MCP server that provides an interface to interact with and query the popular Pokemon API PokeAPI.
You will create a McpServer instance and register a set of tools that the MCP server will expose. The Gemini model will be able to query the list of available tools (tools/list) and invoke particular tools to retrieve information.
const z = require("zod") as typeof import("zod");
const server =
require("@modelcontextprotocol/sdk/server/mcp.js") as typeof import("@modelcontextprotocol/sdk/server/mcp.js");
const mcpServer = new server.McpServer({
name: "PokeAPI MCP Server",
version: "1.0.0",
});tools for the MCP serverThe MCP server will expose a set of tools that the Gemini model can use to interact with the PokeAPI. You can define these tools using the registerTool method of the McpServer instance.
Currently the js-genai SDK does not support prompts and resources, so we will only focus on tools in this example. However, you can still use the MCP server to provide prompts and resources by using registerPrompt and registerResource methods of the McpServer instance.
mcpServer.registerTool(
"getPokemon",
{
title: "Get Pokemon",
description:
"Get information about a Pokemon by its name or ID. Details include abilities, stats, sprites, and more.",
inputSchema: {
nameOrId: z.string().describe("The name or ID of the Pokemon to retrieve information about."),
},
},
async ({ nameOrId }) => {
const response = await fetch(`https://pokeapi.co/api/v2/pokemon/${nameOrId}`);
if (!response.ok) {
throw new Error(`Failed to fetch Pokemon: ${response.statusText}`);
}
return { content: [{ type: "text", text: await response.text() }] };
}
);
mcpServer.registerTool(
"getEvolutionChain",
{
title: "Get Evolution Chain",
description: "Get the evolution chain of a Pokemon by its evolution chain ID. (Available from species endpoint)",
inputSchema: {
evolutionChainId: z
.string()
.describe("The ID of the evolution chain to retrieve. This can be obtained from the species endpoint."),
},
},
async ({ evolutionChainId }) => {
const response = await fetch(`https://pokeapi.co/api/v2/evolution-chain/${evolutionChainId}`);
if (!response.ok) {
throw new Error(`Failed to fetch evolution chain: ${response.statusText}`);
}
return { content: [{ type: "text", text: await response.text() }] };
}
);
mcpServer.registerTool(
"getPokemonSpecies",
{
title: "Get Pokemon Species",
description: "Get information about a Pokemon species by its name or ID.",
inputSchema: {
nameOrId: z.string().describe("The name or ID of the Pokemon species to retrieve information about."),
},
},
async ({ nameOrId }) => {
const response = await fetch(`https://pokeapi.co/api/v2/pokemon-species/${nameOrId}`);
if (!response.ok) {
throw new Error(`Failed to fetch Pokemon species: ${response.statusText}`);
}
return { content: [{ type: "text", text: await response.text() }] };
}
);
mcpServer.registerTool(
"getItem",
{
title: "Get Item",
description: "Get information about an item by its name or ID.",
inputSchema: {
nameOrId: z.string().describe("The name or ID of the item to retrieve information about."),
},
},
async ({ nameOrId }) => {
const response = await fetch(`https://pokeapi.co/api/v2/item/${nameOrId}`);
if (!response.ok) {
throw new Error(`Failed to fetch item: ${response.statusText}`);
}
return { content: [{ type: "text", text: await response.text() }] };
}
);
mcpServer.registerTool(
"getAbility",
{
title: "Get Ability",
description: "Get information about an ability by its name or ID.",
inputSchema: {
nameOrId: z.string().describe("The name or ID of the ability to retrieve information about."),
},
},
async ({ nameOrId }) => {
const response = await fetch(`https://pokeapi.co/api/v2/ability/${nameOrId}`);
if (!response.ok) {
throw new Error(`Failed to fetch ability: ${response.statusText}`);
}
return { content: [{ type: "text", text: await response.text() }] };
}
);
mcpServer.registerTool(
"getMove",
{
title: "Get Move",
description: "Get information about a move by its name or ID.",
inputSchema: {
nameOrId: z.string().describe("The name or ID of the move to retrieve information about."),
},
},
async ({ nameOrId }) => {
const response = await fetch(`https://pokeapi.co/api/v2/move/${nameOrId}`);
if (!response.ok) {
throw new Error(`Failed to fetch move: ${response.statusText}`);
}
return { content: [{ type: "text", text: await response.text() }] };
}
);
console.log("Tools registered successfully");Tools registered successfullyIn this section, you will create a MCP client that connects to the MCP server and invokes the tools exposed by the server. The js-genai SDK provides a mcpToTool function that allows you to convert a MCP tool to Gemini tools.
const client =
require("@modelcontextprotocol/sdk/client/index.js") as typeof import("@modelcontextprotocol/sdk/client/index.js");
const mcpClient = new client.Client({
name: "PokeAPI MCP Client",
version: "1.0.0",
});The MCP server and client communicate over a particular transports. The MCP typescript-sdk provided an InMemoryTransport that allows you to run the MCP server and client in the same process. This is useful for testing and development purposes.
const transport =
require("@modelcontextprotocol/sdk/inMemory.js") as typeof import("@modelcontextprotocol/sdk/inMemory.js");
const transports = transport.InMemoryTransport.createLinkedPair();
await mcpServer.connect(transports[0]);
await mcpClient.connect(transports[1]);You can manually invoke the tools exposed by the MCP server using the callTool method of the McpClient instance. This allows you to test the tools and see how they work before using them in a Gemini model.
type CallToolResult = Awaited<ReturnType<typeof mcpClient.callTool>>;
const result: CallToolResult = await mcpClient.callTool({
name: "getPokemon",
arguments: {
nameOrId: "pikachu",
},
});
console.log(`${(result.content as { text: string }[])[0].text.slice(0, 200)}...`);{"abilities":[{"ability":{"name":"static","url":"https://pokeapi.co/api/v2/ability/9/"},"is_hidden":false,"slot":1},{"ability":{"name":"lightning-rod","url":"https://pokeapi.co/api/v2/ability/31/"},"i...As you can see, the callTool method takes a tool name and its arguments, and returns the result of the tool invocation. In this case, the tool is working as expected and returns the information about the Pokemon with the name "pikachu".
Now that you have a MCP server and client set up, you can integrate it with a Gemini model. The js-genai SDK provides a mcpToTool function that takes a MCP client instance and returns a list of Gemini tools that can be used in a Gemini model.
const mcpChat = ai.chats.create({
model: MODEL_ID,
config: {
tools: [google.mcpToTool(mcpClient)],
toolConfig: {
functionCallingConfig: {
mode: google.FunctionCallingConfigMode.AUTO,
},
},
},
});Let’s create a few utility functions to help us with the integration. These functions will allow you to view the order of function calls and the results of the tool invocations. This will help us understand the reasoning behind the results provided by the Gemini model.
import { Content, FunctionResponse } from "@google/genai";
function printFunctionResponse(response: FunctionResponse) {
const result = response.response;
if (result.content) {
for (const content of result.content as { text: string }[]) {
if (content.text) {
content.text = `${content.text.slice(0, 200)}...`;
}
}
}
console.log("Function Response\n");
console.log(JSON.stringify(result, null, 2));
}
function printFunctionCallingHistory(history: Content[]) {
for (const content of history) {
for (const part of content.parts ?? []) {
if (part.functionCall) {
console.log("Function Call\n");
console.log(JSON.stringify(part.functionCall, null, 2));
}
if (part.functionResponse) {
printFunctionResponse(part.functionResponse);
}
}
}
}// temporarily make console.warn a no-op to avoid warnings in the output (non-text part in GenerateContentResponse caused by accessing .text)
// https://github.com/googleapis/js-genai/blob/d82aba244bdb804b063ef8a983b2916c00b901d2/src/types.ts#L2005
// copy the original console.warn function to restore it later
const warn_fn = console.warn;
// eslint-disable-next-line @typescript-eslint/no-empty-function, no-empty-function
console.warn = function () {};
const response_1 = await mcpChat.sendMessage({
message: "Can you provide the showdown sprites for the pokemon Pikachu?",
});
tslab.display.markdown(response_1.text ?? "");
printFunctionCallingHistory(response_1.automaticFunctionCallingHistory ?? []);Here are the links to the showdown sprites for Pikachu:
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "Pikachu"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"static\",\"url\":\"https://pokeapi.co/api/v2/ability/9/\"},\"is_hidden\":false,\"slot\":1},{\"ability\":{\"name\":\"lightning-rod\",\"url\":\"https://pokeapi.co/api/v2/ability/31/\"},\"i..."
}
]
}function getUrlsFromResponse(response: string): string[] {
const urlRegex = /https?:\/\/[^\s]+/g;
const urls = response.match(urlRegex);
return urls ?? [];
}
const spriteUrls = getUrlsFromResponse(response_1.text ?? "");
tslab.display.html(`<img src="${spriteUrls[0]}" alt="Pikachu Sprite" style="max-width: 200px; max-height: 200px;"/>`);
For comparison, let’s ask the Gemini model the same question without using the MCP server.
const raw_response_1 = await ai.models.generateContent({
model: MODEL_ID,
contents: "Can you provide the showdown sprites for pokemon Pikachu?",
});
tslab.display.markdown(raw_response_1.text ?? "");Since I can’t actually show you an image, I can provide a detailed textual description of what a showdown-style sprite for Pikachu would look like, focusing on its common battle stance and animated elements:
Pikachu (Showdown Style Sprite Description)
Pikachu is rendered in a crisp, clean pixel-art style, typical of Pokémon Showdown, facing slightly to the right (as if facing an opponent). Its body is a vibrant, electric yellow, plump and rounded, giving it a sturdy yet agile appearance.
Key Features & Pose:
Overall Impression (as an animated sprite):
The sprite would continuously loop a subtle animation – a gentle bobbing of its body, a soft flicker in its cheek pouches, perhaps a slight twitch of its tail or ears. This makes Pikachu look alive, energetic, and constantly prepared for action on the battlefield. The colors are bright and distinct, making it instantly recognizable and impactful.
Gemini models can invoke multiple tools in a single request. This is useful when you want to gather information from multiple sources or perform multiple actions in a single request, cross-referencing the results of multiple tools.
const response_2 = await mcpChat.sendMessage({
message: "What abilities does Pikachu have, and what does each one do?",
});
tslab.display.markdown(response_2.text ?? "");
printFunctionCallingHistory(
(response_2.automaticFunctionCallingHistory ?? []).slice(response_1.automaticFunctionCallingHistory.length + 1)
);Pikachu has two abilities: Static and Lightning Rod.
Static: When a Pokémon with Static is hit by a move that makes contact, there is a 30% chance that the attacking Pokémon will be paralyzed. Even Pokémon that are normally immune to Electric-type moves can be paralyzed by this ability. Additionally, if a Pokémon with Static is at the head of your party, there is a 50% chance of encountering an Electric-type Pokémon in the wild, if one is available in the area.
Lightning Rod: A Pokémon with Lightning Rod will draw all single-target Electric-type moves to itself. Instead of taking damage, the Pokémon’s Special Attack is raised by one stage. This ability will not redirect a move if the intended target also has Lightning Rod. If multiple Pokémon with this ability are on the field, the one with the highest Speed stat will be the one to redirect the move.
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "pikachu"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"static\",\"url\":\"https://pokeapi.co/api/v2/ability/9/\"},\"is_hidden\":false,\"slot\":1},{\"ability\":{\"name\":\"lightning-rod\",\"url\":\"https://pokeapi.co/api/v2/ability/31/\"},\"i..."
}
]
}
Function Call
{
"name": "getAbility",
"args": {
"nameOrId": "static"
}
}
Function Call
{
"name": "getAbility",
"args": {
"nameOrId": "lightning-rod"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"effect_changes\":[{\"effect_entries\":[{\"effect\":\"Hat außerhalb vom Kampf keinen Effekt.\",\"language\":{\"name\":\"de\",\"url\":\"https://pokeapi.co/api/v2/language/6/\"}},{\"effect\":\"Has no overworld effect.\",\"l..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"effect_changes\":[{\"effect_entries\":[{\"effect\":\"Hat außerhalb vom Kampf keinen Effekt.\",\"language\":{\"name\":\"de\",\"url\":\"https://pokeapi.co/api/v2/language/6/\"}},{\"effect\":\"Has no overworld effect.\",\"l..."
}
]
}const response_3 = await mcpChat.sendMessage({
message: "What is the flavor text for Ralts's species, and what is it's evolution chain and directions?",
});
tslab.display.markdown(response_3.text ?? "");
printFunctionCallingHistory(
(response_3.automaticFunctionCallingHistory ?? []).slice(response_2.automaticFunctionCallingHistory.length + 1)
);Ralts’s flavor text is: “It is highly attuned to the emotions of people and Pokémon. It hides if it senses hostility.”
Ralts’s evolution chain is as follows:
Function Call
{
"name": "getPokemonSpecies",
"args": {
"nameOrId": "ralts"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"base_happiness\":35,\"capture_rate\":235,\"color\":{\"name\":\"white\",\"url\":\"https://pokeapi.co/api/v2/pokemon-color/9/\"},\"egg_groups\":[{\"name\":\"humanshape\",\"url\":\"https://pokeapi.co/api/v2/egg-group/8/\"},{..."
}
]
}
Function Call
{
"name": "getEvolutionChain",
"args": {
"evolutionChainId": "140"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"baby_trigger_item\":null,\"chain\":{\"evolution_details\":[],\"evolves_to\":[{\"evolution_details\":[{\"gender\":null,\"held_item\":null,\"item\":null,\"known_move\":null,\"known_move_type\":null,\"location\":null,\"min_..."
}
]
}The Gemini model can also perform multi-step reasoning and tasks. This means that the model can break down a complex task into smaller sub-tasks and invoke multiple tools to complete the task by reasoning about the results of the previous steps.
const response_4 = await mcpChat.sendMessage({
message: "What are a list of Pokemon which have the ability 'Dancer' and are 'electric' type?",
});
tslab.display.markdown(response_4.text ?? "");
printFunctionCallingHistory(
(response_4.automaticFunctionCallingHistory ?? []).slice(response_3.automaticFunctionCallingHistory.length + 1)
);Oricorio Pom-Pom is the only Pokémon with the ability ‘Dancer’ and the type ‘electric’. Other Oricorio forms have the ‘Dancer’ ability but different types: Baile Style is Fire/Flying, Pau Style is Psychic/Flying, and Sensu Style is Ghost/Flying.
Function Call
{
"name": "getAbility",
"args": {
"nameOrId": "Dancer"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"effect_changes\":[],\"effect_entries\":[{\"effect\":\"Whenever another Pokémon uses a dance move, this Pokémon will use the same move immediately afterwards.\",\"language\":{\"name\":\"en\",\"url\":\"https://pokeap..."
}
]
}
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "oricorio-pom-pom"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"dancer\",\"url\":\"https://pokeapi.co/api/v2/ability/216/\"},\"is_hidden\":false,\"slot\":1}],\"base_experience\":167,\"cries\":{\"latest\":\"https://raw.githubusercontent.com/PokeAP..."
}
]
}
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "oricorio-baile"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"dancer\",\"url\":\"https://pokeapi.co/api/v2/ability/216/\"},\"is_hidden\":false,\"slot\":1}],\"base_experience\":167,\"cries\":{\"latest\":\"https://raw.githubusercontent.com/PokeAP..."
}
]
}
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "oricorio-pau"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"dancer\",\"url\":\"https://pokeapi.co/api/v2/ability/216/\"},\"is_hidden\":false,\"slot\":1}],\"base_experience\":167,\"cries\":{\"latest\":\"https://raw.githubusercontent.com/PokeAP..."
}
]
}
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "oricorio-sensu"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"dancer\",\"url\":\"https://pokeapi.co/api/v2/ability/216/\"},\"is_hidden\":false,\"slot\":1}],\"base_experience\":167,\"cries\":{\"latest\":\"https://raw.githubusercontent.com/PokeAP..."
}
]
}const response_5 = await mcpChat.sendMessage({
message:
"Can you devise a moveset for my Mewtwo? It should be a competitive moveset with elaborate reasoning for each move, take into account utility moves and type coverage of moves. (When you get a pokemon it comes with its moveset of all learnable moves, from there shortlist possible moves (less that 10) and then pick the best 4 moves for the moveset with best utility and coverage for showdown, this descision can be made using the getMove tool to get move information and reasoning).",
});
tslab.display.markdown(response_5.text ?? "");
printFunctionCallingHistory(
(response_5.automaticFunctionCallingHistory ?? []).slice(response_4.automaticFunctionCallingHistory.length + 1)
);Of course! Here is a competitive moveset for your Mewtwo, designed for success in Pokémon Showdown:
Mewtwo is a legendary Pokémon with an incredible Special Attack stat of 154 and a blistering Speed stat of 130. This makes it one of the most powerful special sweepers in the game. The goal of this moveset is to maximize its offensive potential while providing coverage against a wide range of opponents.
Let’s start by looking at a shortlist of potential moves:
After careful consideration, here are the two best movesets for Mewtwo:
This moveset focuses on immediate offensive pressure and wide type coverage.
| Move | Type | Category | Power | Accuracy |
|---|---|---|---|---|
| Psystrike | Psychic | Special | 100 | 100% |
| Aura Sphere | Fighting | Special | 80 | ∞ |
| Ice Beam | Ice | Special | 90 | 100% |
| Fire Blast | Fire | Special | 110 | 85% |
Reasoning:
This moveset is designed to set up and sweep the opposing team.
| Move | Type | Category | Power | Accuracy |
|---|---|---|---|---|
| Calm Mind | Psychic | Status | - | - |
| Psystrike | Psychic | Special | 100 | 100% |
| Aura Sphere | Fighting | Special | 80 | ∞ |
| Recover | Normal | Status | - | - |
Reasoning:
For an even more offensive setup, you can replace Calm Mind with Nasty Plot, which doubles Mewtwo’s Special Attack in a single turn, but at the cost of not boosting its Special Defense.
Both of these movesets are incredibly powerful and can be adapted to your playstyle. Good luck in your battles
Function Call
{
"name": "getPokemon",
"args": {
"nameOrId": "mewtwo"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"abilities\":[{\"ability\":{\"name\":\"pressure\",\"url\":\"https://pokeapi.co/api/v2/ability/46/\"},\"is_hidden\":false,\"slot\":1},{\"ability\":{\"name\":\"unnerve\",\"url\":\"https://pokeapi.co/api/v2/ability/127/\"},\"is_..."
}
]
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "psystrike"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "aura-sphere"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "shadow-ball"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "ice-beam"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "flamethrower"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "fire-blast"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "calm-mind"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "recover"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "nasty-plot"
}
}
Function Call
{
"name": "getMove",
"args": {
"nameOrId": "taunt"
}
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":100,\"contest_combos\":null,\"contest_effect\":null,\"contest_type\":null,\"damage_class\":{\"name\":\"special\",\"url\":\"https://pokeapi.co/api/v2/move-damage-class/3/\"},\"effect_chance\":null,\"effect_ch..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":null,\"contest_combos\":null,\"contest_effect\":null,\"contest_type\":{\"name\":\"beauty\",\"url\":\"https://pokeapi.co/api/v2/contest-type/2/\"},\"damage_class\":{\"name\":\"special\",\"url\":\"https://pokeapi...."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":100,\"contest_combos\":null,\"contest_effect\":{\"url\":\"https://pokeapi.co/api/v2/contest-effect/22/\"},\"contest_type\":{\"name\":\"smart\",\"url\":\"https://pokeapi.co/api/v2/contest-type/4/\"},\"damage_..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":100,\"contest_combos\":null,\"contest_effect\":{\"url\":\"https://pokeapi.co/api/v2/contest-effect/23/\"},\"contest_type\":{\"name\":\"beauty\",\"url\":\"https://pokeapi.co/api/v2/contest-type/2/\"},\"damage..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":100,\"contest_combos\":{\"normal\":{\"use_after\":[{\"name\":\"sunny-day\",\"url\":\"https://pokeapi.co/api/v2/move/241/\"}],\"use_before\":null},\"super\":{\"use_after\":null,\"use_before\":null}},\"contest_eff..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":85,\"contest_combos\":{\"normal\":{\"use_after\":[{\"name\":\"sunny-day\",\"url\":\"https://pokeapi.co/api/v2/move/241/\"}],\"use_before\":null},\"super\":{\"use_after\":null,\"use_before\":null}},\"contest_effe..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":null,\"contest_combos\":{\"normal\":{\"use_after\":null,\"use_before\":[{\"name\":\"psybeam\",\"url\":\"https://pokeapi.co/api/v2/move/60/\"},{\"name\":\"confusion\",\"url\":\"https://pokeapi.co/api/v2/move/93/\"..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":null,\"contest_combos\":null,\"contest_effect\":{\"url\":\"https://pokeapi.co/api/v2/contest-effect/23/\"},\"contest_type\":{\"name\":\"smart\",\"url\":\"https://pokeapi.co/api/v2/contest-type/4/\"},\"damage..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":null,\"contest_combos\":null,\"contest_effect\":null,\"contest_type\":{\"name\":\"cute\",\"url\":\"https://pokeapi.co/api/v2/contest-type/3/\"},\"damage_class\":{\"name\":\"status\",\"url\":\"https://pokeapi.co/..."
}
]
}
Function Response
{
"content": [
{
"type": "text",
"text": "{\"accuracy\":100,\"contest_combos\":{\"normal\":{\"use_after\":null,\"use_before\":[{\"name\":\"counter\",\"url\":\"https://pokeapi.co/api/v2/move/68/\"},{\"name\":\"detect\",\"url\":\"https://pokeapi.co/api/v2/move/197/\"},{..."
}
]
}Some tools can return multi-modal output, such as images or videos. The Gemini model can handle these outputs and process them accordingly. For example, you can chain multiple models to generate an image based on the output of a previous model, or use a tool that returns an image and then process that image with another model.
const artwork = await ai.models.generateContent({
model: MODEL_ID,
contents: "Can you provide the shiny official artwork sprite for 'Mega Rayquaza'?",
config: {
tools: [google.mcpToTool(mcpClient)],
toolConfig: {
functionCallingConfig: {
mode: google.FunctionCallingConfigMode.AUTO,
},
},
},
});
tslab.display.markdown(artwork.text ?? "");Here is the shiny official artwork sprite for Mega Rayquaza: https://raw.githubusercontent.com/PokeAPI/sprites/master/sprites/pokemon/other/official-artwork/shiny/10079.png
const artworkUrl = getUrlsFromResponse(artwork.text ?? "")[0];
const artworkBlob = await fetch(artworkUrl).then((res) => res.blob());
const backgroundDescription = await ai.models.generateContent({
model: MODEL_ID,
contents: [
"Can you provide a detailed description of a background suitable for 'Mega Rayquaza' in a Pokemon game, take the sprite aesthetics into account? Include details about the environment, colors, and any notable features.",
google.createPartFromBase64(Buffer.from(await artworkBlob.arrayBuffer()).toString("base64"), "image/png"),
],
});
tslab.display.markdown(backgroundDescription.text ?? "");Let’s craft a background that perfectly complements Mega Rayquaza’s awe-inspiring sprite, emphasizing its cosmic power and imposing presence, while adhering to the stylized nature of a Pokemon game.
Background Description for Mega Rayquaza
This background aims to evoke a sense of immense altitude, celestial power, and the volatile energy that defines Mega Rayquaza. It’s a dynamic blend of the upper atmosphere and the void of space, serving as a stage for this legendary bringer of order.
1. Overall Environment: The Stratospheric Divide
The scene depicts a turbulent, yet majestic, view from incredibly high altitudes – specifically, the boundary between Earth’s outer atmosphere and the beginnings of deep space. It’s not a clear blue sky, but rather a dramatic, twilight-tinged vista where atmospheric phenomena meet cosmic stillness. The angle is slightly looking down from Mega Rayquaza’s perspective, emphasizing its dominance over the world below.
2. Color Palette:
The color scheme is designed to make Mega Rayquaza’s prominent black body and vibrant red/orange accents pop with maximum contrast and impact.
3. Notable Features & Effects:
In essence, the background would be a dramatic, almost painterly representation of the highest skies, infused with cosmic energy, making Mega Rayquaza appear as the ultimate cosmic serpent, guardian of the celestial frontier.
import { GenerateContentResponse } from "@google/genai";
const IMAGE_GENERATION_MODEL_ID = "gemini-2.0-flash-preview-image-generation";
function displayResponse(response: GenerateContentResponse) {
for (const part of response.candidates?.[0]?.content?.parts ?? []) {
if (part.text) {
tslab.display.markdown(part.text);
} else if (part.inlineData) {
const imageData = part.inlineData.data!;
const buffer = Buffer.from(imageData, "base64");
}
}
}
const response = await ai.models.generateContent({
model: IMAGE_GENERATION_MODEL_ID,
contents: [
`
Include the supplied sprite as the main subject of the image, and generate a background that fits the sprite's aesthetics.
Background:
${backgroundDescription.text ?? ""}
`,
google.createPartFromBase64(Buffer.from(await artworkBlob.arrayBuffer()).toString("base64"), "image/png"),
],
config: {
responseModalities: [google.Modality.TEXT, google.Modality.IMAGE],
},
});
displayResponse(response);I will generate an image of the provided Mega Rayquaza sprite set against a dramatic background depicting the stratospheric divide. The upper portion of the image will transition from deep indigo to cosmic black with faint nebulous hues and sparse stars. The mid-ground will feature turbulent, dark grey-blue and purple storm clouds with a fiery orange-red underglow. The lower portion will show a barely visible, dark curve of the Earth’s horizon with faint, flickering blue-white lightning in distant clouds. Subtle streaks of red-orange energy will drift across the scene, enhancing the sense of cosmic power, all designed to highlight Mega Rayquaza as the central focus.
In this guide, you learned how to build a MCP server using the modelcontextprotocol/typescript-sdk SDK and how to connect it to a Gemini model. You also learned how to define tools for the MCP server, invoke them manually, and integrate them with a Gemini model. Finally, you explored multi-tool invocation, multi-step reasoning, and multi-modal output capabilities of the Gemini model.
You can explore more advanced features of the MCP server, such as defining prompts and resources, or using the MCP server in a production environment. You can also experiment with different models and see how they perform with the MCP server. For more information, check out the MCP documentation.
